Hydraulic Power Packs for Dump Trailer Place of Origin:China Brand Name:HCIC Minimum Order Quantity:50 sets Packaging Details:Packed in carton boxes ,and then wooden pallets Delivery Time:25work days Payment Terms:T/T, Western Union, Supply Ability:500 sets/month Motor:DC 24V 1.6kW 2500RPM Moungting Type:Horizontal Oil Pump:2.1cc/r Tank Size:5L Oil Port:G3/8'' Mounting Type:Horizontal High Light:electric hydraulic power pack,portable hydraulic power pack
DC 24V 1600W Power Packs for Dump Trailer
Overview:
This Hydraulic Power Unit is to operate single acting cylinders, complete with 2 buttons remote and cable.
DC 24V Hydraulic power unit.
DC24V 1600w motor
2.1cc/r gear pump.
plastic motor cover.CODE:MC-02
5L plastic tank with drain plug.
Hydraulic Power pack complete with suction filter, remote,return oil pipe and air breather.
Mounting: Horizontal Mounting.
Max pressure: 16Mpa.
Relief valve: RV2-08. set pressure 160 bar, but adjustable from 40-230 bar as standard for each single acting hydraulic power pack.
Check Valve:CV2-08. Non-return Valve to keep cylinder stay .
Flow Rate: 5 l/min.
Relief valve and check valve for all standard power unit
Oil Port size :3/8"BSP
2 Button remote with 4 metre cable.
Power Packs suitable for all kinds of single acting Hydraulic cylinders.
It is widely use in many fields like the following:
Hydraulic cylinder application field:
1. Applicable to machine tool industry
2. Suitable for family use
3. Applicable to metallurgical industry
4. Applicable to engineering industry
5. Applicable to agricultural machinery
6. Applicable to the automobile industry
7.Applicable to light textile industry
Feature of Hydraulic Power Packs for Dump Trailer:
High Performance: Engineered for optimal hydraulic performance to meet the demanding needs of dump trailers.
Durable Construction: Built with robust materials to withstand heavy usage and harsh environmental conditions.
Precise Control: Equipped with advanced controls to ensure precise and efficient operation of the dump trailer hydraulics.
Compact Design: Despite its power, the unit is designed to be compact, allowing for easy integration and space-saving.
Specification of Hydraulic Power Packs for Dump Trailer:
All parameters can be customized
Parameters of the sample
Technical Parameters
Mini Hydraulic Power Unit Pack|
Minimum Order Quantity |
50sets |
|
Product name |
Hydraulic power pack |
|
Pressure |
16Mpa or required |
|
Brand Name |
HCIC |
|
Oil tank |
6L-12L |
|
Power |
0.75KW/1.5KW/2.2KW |
|
Installation |
vertical or horizontal |
|
Condition |
New |
|
Oil Port |
G3/8" |
|
Displacement |
2.1ml/r or required |
Production of Hydraulic Power Packs for Dump Trailer:
Our state-of-the-art manufacturing facility employs the latest technologies, allowing us to produce superior hydraulic power packs for diverse applications.
Our Service:
Customization: Tailoring our products to match individual customer needs, ensuring optimal performance and satisfaction.Technical Expertise: Providing extensive technical knowledge and support to assist customers in effectively utilizing our products.Customer-Centric Approach: Our customers are at the core of our business, and we prioritize their needs and preferences in everything we do.
Why choose us?
Innovative Solutions: We constantly innovate our products to incorporate the latest advancements, offering cutting-edge solutions to our clients.Reliability: Our hydraulic power packs are built for reliability, ensuring consistent performance even under challenging conditions.Global Reach: Leveraging a robust logistics network, we efficiently deliver our products to customers worldwide.
FAQ:
Can the Hydraulic Power Packs for Dump Trailer be used in extreme weather conditions?
Yes, our power packs are designed to operate effectively within a broad temperature range, making them suitable for various climates.
Is it possible to customize the reservoir capacity of the power pack?
Yes, we offer customization options for reservoir capacity to align with your specific requirements.
Packing & Shipping:
Efficient logistics ensure timely and secure delivery to our customers worldwide.
