Cylinder Type: Welded
Action: Single-Acting
Bore (ID): 1.5″
Stroke: 12″
Rod (OD): 1.25″
Mounting Type: Hole
Mounting Pin (OD): 1″
Rod End Type: Hole
Rod End Pin (OD): 1″
Work Ports: 1/4″ NPT(F)
Max Working Pressure: 3,000 PSI
Retracted Length: 19.25″ (pin to pin, center on center)
Extended Length: 31.25″ (pin to pin, center on center)
Cylinder Length: 20.75″ (retracted, edge to edge)
Column Load: 5306 lbs
Product Weight: 15.6 lbs
Barrel Material: Quenched and tempered steel (ASIS 1020)
Rod Material: High tensile ground and polished chrome plated steel (ASIS 1045)
Gland Material: High tensile nodular cast iron (ASTM A536 grade 70-50-05)
Piston Material: High tensile nodular cast iron (ASTM A536 grade 70-50-05)
